| Physical Property | |
| System | Android |
| RAM | 512MB |
| ROM | 8GB |
| Front Panel | Aluminum |
| Power Supply | PoE (802.3af) or DC12V/2A |
| Standby Power | 3W |
| Rated Power | 13W |
| Camera | 2MP, CMOS, WDR |
| IR Sensor | Support |
| Door Entry | Face, IC card(13.56MHz), PIN code, APP |
| IP Rating | IP65 (Seal up the cracks between door station and the wall with glass glue.) |
| Installation | Flush mounting |
| Dimension | 400 x 180 x 45mm |
| Working Temperature | -20℃ - +55℃ |
| Storage Temperature | -40℃ - +70℃ |
| Working Humidity | 10%-90% (non-condensing) |
| Display | |
| Display | 10.1-inch TFT LCD |
| Screen | 10.1-inch capacitive touch screen |
| Resolution | 1024 x 600 |
| Audio & Video | |
| Audio Codec | G.711 |
| Video Codec | H.264 |
| Video Resolution | up to 1920 x 1080 |
| Viewing Angle | 100°(D) |
| Light Compensation | LED white light |
| Networking | |
| Protocol | SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPV4, ARP, ICMP |
| Port | |
| Wiegand Port | Support |
| Ethernet Port | 1 x RJ45, 10/100 Mbps adaptive |
| RS485 Port | 1 |
| Relay Out | 1 |
| Exit Button | 1 |
| Door Magnetic | 1 |
-
Datasheet 904M-S3.pdfDownload
