| Harta fisik | |
| Sistem | Samid |
| Ram | 2GB |
| Rom | 8GB |
| Panel hareup | Aluminium |
| Sasayogian tanaga | Dc12v / 2A atanapi ieee 802.3at PoE + |
| Daya sayaga | 5w |
| Power dipeunteun | 25d |
| Kamera | 2mp, CMOS, WDR |
| Sensor IR | Dukungan |
| Éntri panto | Beungeut, kartu IC (13,56mhz), kode PIN, NFC |
| Rating IP | Ip65 (segel retakan antara pantoStasion sareng témbok sareng lem gelas.) |
| Instalasi | Semi-sireum ningkat |
| Ukuran produk | 227 x 122 x 39,2 mm |
| Ukuran instalasi | 185 x 67 x 51 mm |
| Suhu gawe | -40 ℃ - + 55 ℃ |
| Kerulan neundeun | -40 ℃ - + 70 ℃ |
| Kalembaban damel | 10% -90% (non-condensing) |
| Mamerkeun | |
| Mamerkeun | 7-inci IPS LCD |
| Layar | 3-inci layar témpél |
| Resolusi | 1024 x 600 |
| Audio & pidéo | |
| Kodeu audio | G.711 |
| Kodeu pidéo | H.264 |
| Resolusi pidéo | dugi ka 1920 x 1080 |
| Nempo sudut | 100 ° (D) |
| Instrumen lampu | Lampu bodas led |
| Arkasi | |
| Protocol | SIP, ADP, TCP, RTP, NTP, DNS, http, DHCP, IPV4, Acv4, Acvmp |
| Palabuhan | |
| Palabuhan wiegand | Dukungan |
| Palabuhan Ethernet | 1 x RJ45, 10/100 Mbps |
| Palabuhan Rs485 | Panon kentang. |
| Relay kaluar | Panon kentang. |
| Kaluar tombol | Panon kentang. |
| Panto magnét | Panon kentang. |
-
Datasheet 904m-s3.pdfUnduh
Datasheet 904m-s3.pdf
